Device Architecture
Terminology
Conversion Time
Conversion time is the interval between the release of the hold state (imposed by the input
circuitry of a track-and-hold) and the instant at which the voltage on the sampling capacitor settles
to within one LSB of a new input value.
DNL – Differential Non-Linearity
For an ideal ADC, the analog-input levels that trigger any two successive output codes should differ
by one LSB (DNL = 0). Any deviation from one LSB in defined as DNL (Figure 2-84).
Ideal Output
Actual Output
Error = –0.5 LSB
Error = +1 LSB
Input Voltage to Prescaler
Figure 2-84 • Differential Non-Linearity (DNL)
ENOB – Effective Number of Bits
ENOB specifies the dynamic performance of an ADC at a specific input frequency and sampling
rate. An ideal ADC’s error consists only of quantization of noise. As the input frequency increases,
the overall noise (particularly in the distortion components) also increases, thereby reducing the
ENOB and SINAD (also see “Signal-to-Noise and Distortion Ratio (SINAD)”.) ENOB for a full-scale,
sinusoidal input waveform is computed using EQ 2-20.
SINAD – 1.76
ENOB = ----------------------------------
6.02
EQ 2-20
FS Error – Full-Scale Error
Full-scale error is the difference between the actual value that triggers that transition to full-scale
and the ideal analog full-scale transition value. Full-scale error equals offset error plus gain error.
2-110
Preliminary v1.7
