FEDL87V2107-01
OKI Semiconductor
ML87V2107
2.3.3 2DLPF Noise Reduction Auto ON/OFF
By setting AYLPF[2:1](SUB:65h-bit[7:6]) and ACLPF[2:1](SUB:66h-bit[7:6]) in the I2C-bus interface, the
noise reduction ON/OFF function can be set using the noise checking flag (YDTO1, YDTO2, CDTO1, CDTO2).
When using the automatic ON/OFF function, set YLPFON = 0 and CLPFON = 0.
Table F2-3-3(1) Luminance 2DLPF Auto ON/OFF Setting
AYLPF
Luminance
2DLPF
YDTO1
YDTO2
[2]
[1]
0
0
X
0
1
1
0
1
1
X
0
0
1
0
0
1
OFF
OFF
ON
0
1
0
ON
OFF
OFF
ON
1
Table F2-3-3(2) Chrominance 2DLPF Auto ON/OFF Setting
ACLPF
Chrominance
2DLPF
CDTO1
CDTO2
[2]
[1]
0
0
X
0
1
1
0
1
1
X
0
0
1
0
0
1
OFF
OFF
ON
0
1
0
ON
OFF
OFF
ON
1
2.3.4 2DLPF Memo Board
By setting ODEMO[1:0](SUB:64h-bit[7:6]) in the I2C-bus interface, the 2DLPF noise reduction function can be
checked as a demonstration mode by splitting the screen as shown in Figure F2-3-3.
Table F2-3-4 ODEMO Setting
ORDEMO
Left side of screen
Right side of screen
[1]
0
[0]
0
YLPFON, CLPFON setting
2DLPFOFF
YLPFON, CLPFON setting
YLPFON, CLPFON setting
YLPFON, CLPFON setting
0
1
1
0
Normal 2DLPF
Left side area of
screen
Right side area of
screen
Figure F2-3-3 2DLPF Noise Reduction Demo Screen
74/152
