FEDL87V2107-01
OKI Semiconductor
ML87V2107
2.4.3 Output Memory Control Settings (phase adjustment)
SUB_ADDRESS=62h(W/R): Sets vertical phase adjustment of output memory control
DATA_BIT
BIT7
BIT6
BIT5
BIT4
BIT3
BIT2
BIT1
1
BIT0
0
NPVRE
Register name (Reserved) (Reserved) (Reserved) (Reserved)
3
2
SUB_ADDRESS=63h(W/R): Sets horizontal phase adjustment of output memory control
DATA_BIT
BIT7
BIT6
BIT5
BIT4
BIT3
NPHRE
BIT2
BIT1
1
BIT0
0
Register name
7
6
5
4
3
2
NPVRE[3:0] Initial value: 1000; Setting range: 0001 to 1111
Sets the number of lines up to the standard read starting position in the vertical direction after OVS falls.
NPHRE[7:0] Initial value: 1000_0000; Setting range: 0000_0001 to 1111_1111
Sets the number of pixels (OCLK) up to the standard read starting position in the horizontal direction
from the rise of OHS.
137/152
