VT82C686B
SUSC#) are provided to turn off more system power planes as
the system moves to deeper power-down states, i.e., from
normal operation to POS (only SUSA# asserted), to STR (both
SUSA# and SUSB# asserted), and to STD (all three SUS#
signals asserted). In particular, the assertion of SUSC# can be
used to turn off the VCC supply to the VT82C686B.
System Suspend States and Power Plane Control
There are three power planes inside the VT82C686B. The
first power plane (VCCS) is always on unless turned off by the
mechanical switch. The second power plane (VCC) is
controlled by chip output SUSC# (also called “PSON”). The
third plane (VCCRTC) is powered by the combination of the
VCCS and the external battery (VBAT) for the integrated real
time clock. Most of the circuitry inside the VT82C686B is
powered by VCC. The amount of logic powered by VCCS is
very small; its main function is to control the supply of VCC
and other power planes. VCCRTC is always on unless both the
mechanical switch and VBAT are removed.
One additional suspend status indicator (SUSST1#) is
provided to inform the north bridge and the rest of the system
of the processor and system suspend states. SUSST1# is
asserted when the system enters the suspend state or the
processor enters the C3 state. SUSST1# is connected to the
north bridge to switch between normal and suspend-DRAM-
refresh modes.
The VT82C686B supports multiple system suspend states by
configuring the SLP_TYP field of ACPI I/O space register
Rx4-5:
General Purpose I/O Ports
As ACPI compliant hardware, the VT82C686B includes
PWRBTN#, SLPBTN#, and RI# pins to implement power
button, sleep button, and ring indicator functionality,
respectively. Furthermore, the VT82C686B offers many
general-purpose I/O ports with the following capabilities:
Most devices in the
a) POS (Power On Suspend):
system remain powered. The host bus is put into an
equivalent of the C3 state. In particular, the CPU is
put into the Stop Grant State or Stop Clock State
depending on the setting of the HOST_STP bit.
SUSST1# is asserted to tell the north bridge to switch
to “Suspend DRAM Refresh” mode based on the
32KHz SUSCLK provided by the VT82C686B. As
to the PCI bus, setting the PCLK_RUN bit to 0
enables the CLKRUN protocol defined in the PCI
Mobile Design Guide. That is, the PCKRUN# pin
will be de-activated after the PCI bus is idle for 26
clocks. Any PCI bus masters including the north
bridge may resume PCI clock operation by pulling
the PCKRUN# pin low. During the PCKRUN# de-
activation period, the PCISTP# pin may be activated
to disable the output of the PCI clock generator if the
PCI_STP bit is enabled. When the system resumes
from POS, the VT82C686B can optionally resume
without resetting the system, can reset the processor
only, or can reset the entire system. When no reset is
performed, the chip only needs to wait for the clock
synthesizer and processor PLL to lock before the
system is resumed, which typically takes 20ms.
I2C/SMB Support
•
•
•
•
•
Thermal Detect
Notebook Lid Open/Close Detect
Battery Low Detect
(multiplexed with
Twelve General Purpose Input Ports
other functions).
•
•
(1 dedicated
Nineteen General Purpose Output Ports
and 18 multiplexed with other functions)
Four General Purpose Input
/
Output Ports
(multiplexed with other functions)
In addition, the VT82C686B provides an external dedicated
SMI pin (EXTSMI#). The external SMI input can be
programmed to trigger an SCI or SMI at both the rising and
falling edges of the corresponding input signal. Software can
check the status of the input pin and take appropriate actions.
Power is removed from
b) STR (Suspend to RAM):
most of the system except the system DRAM. Power
is supplied to the suspend refresh logic in the north
bridge (VTT of VT82C598) and the suspend logic of
the VT82C686B (VCCS).
The VT82C686B
provides a 32KHz suspend clock to the north bridge
for it to use to continue DRAM refresh.
Power
c) STD (Suspend to Disk, also called Soft-off):
is removed from most of the system except the
suspend logic of VT82C686B (VCCS).
This is not a suspend state. All
d) Mechanical Off:
power in the system is removed except the RTC
battery.
The suspend state is entered by setting the SLP_EN bit to 1.
Three power plane control signals (SUSA#, SUSB# and
