EAGLE
PRELIMINARY
Ver 1.3
-
Supports RGB 565
Video Decoder Interface Module(Including CSC Image Capturer)
-
-
-
-
-
Supports data input format 4:2:2, 8-bit YCbCr
Supports Interlace / Non-interlace Mode
Color Space Conversion
R/G/B Gain Control
X/Y Down Scaling Mode and Display Position Control
Local Memory Controller
-
-
-
-
-
-
-
-
-
-
Local / Frame Shared Memory (Local / Frame / Texture @ Non-texture memory mode)
64 MBytes address space per each Bank
Supports 7 Memory Banks
Supports External Wait Signal to Expand The Bus Cycle
Supports Self-refresh Mode in SDRAM for Power-down
Supports SDRAM and Asynchronous type devices.
Supports SDRAM of Full Page Mode
8/16/32-bit SRAM memory interface
32-bit SDRAM memory interface
Includes direct write FIFO to enable fast burst mode write to frame buffer by the CPU
Texture Memory Controller
-
-
-
Max 128 MBytes address space
16-bit memory interface
Supports SDRAM of Full Page Mode
H.264 Decoder & Scaler
-
-
-
-
H.264/AVC Baseline Compatible
CIF 30 frame/sec @ 27MHz
Supports decoding of YCbCr (4:2:0) format video
Supports Scaling up to 720x480
JPEG Decoder
-
-
-
-
-
-
-
-
ISO 10918-2 Base line JPEG Decoder
Only supports Typical Huffman Table defined in annex K of standard.
Supports YCbCr 4:2:2 / 4:2:0 Format
Maximum Resolution:1024x768
Only supports multiple of 32 image width
Only supports multiple of 8 image height on 4:2:2 image format
Only supports multiple of 16 image height on 4:2:0 image format
Supports RGB 565 or RGB 888 output format
Sound Mixer
-
-
-
-
-
-
Maximum 8 Channel
Sampling Range 0.172kHz ~ 88.2kHz
Supports 4-ADPCM, 8/16-bit PCM
Supports Volume and Left/Right Balance Control
Output in Stereo 16-bit MSB (Left)-justified format
I2S Audio Codec I/F (MCLK-384fs, SCLK-32fs)
SD Card Controller
-
-
-
-
Supports SD Memory Card (ver 1.1) / MMC (ver 3.31) compatible
Supports high speed (50 MHz)
Supports 1-bit / 4-bit data bus
Supports DMA data transfer
Peripheral functions
-
-
-
-
-
-
-
-
-
-
-
-
-
2 Ch. GDMA
I2S with ADPCM
Key Scan (Max. 5 x 5)
Programmable Priority Interrupt controller
Watch Dog Timer
4 Ch. UART with 16 * 8 bit FIFO
USB Host/Device Controller ( supports only full speed (12Mb/s) )
GPIO
4 Ch. Timer ( All Ch. are available for PWM/Capture ).
Nand Flash Controller ( supports Auto-Boot mode )
TWI
RTC
SPI
