LHF80V25
33
sharp
6.2.7 RESET OPERATIONS
High Z
RY/BY#(R)
VOL
VIH
RP#(P)
VIL
tPLPH
(A)Reset During Read Array Mode
High Z
RY/BY#(R)
VOL
tPLRZ
VIH
RP#(P)
VIL
tPLPH
(B)Reset During Block Erase or Word/Byte Write
5V
VCC
VIL
t5VPH
VIH
RP#(P)
VIL
(C)RP# rising Timing
Figure 15. AC Waveform for Reset Operation
Reset AC Specifications
V
=4.5V-5.5V
Max.
CC
Sym.
Parameter
Notes
Min.
Unit
ns
RP# Pulse Low Time
t
100
PLPH
(If RP# is tied to V , this specification is not applicable)
CC
t
t
RP# Low to Reset during Block Erase or Word/Byte Write
1,2
3
12
µs
ns
PLRZ
5VPH
V
4.5V to RP# High
100
CC
NOTES:
1. If RP# is asserted while a block erase or word/byte write operation is not executing, the reset will complete within 100ns.
2. A reset time, t , is required from the later of RY/BY# going High Z or RP# going high until outputs are valid.
PHQV
3. When the device power-up, holding RP# low minimum 100ns is required after V has been in predefined range and also
CC
has been in stable there.
Rev. 1.1
