LD7575
Absolute Maximum Ratings
Supply Voltage VCC
30V
High-Voltage Pin, HV
-0.3V~500V
-0.3 ~7V
150°C
COMP, RT, CS
Junction Temperature
Operating Ambient Temperature
Storage Temperature Range
-40°C to 85°C
-65°C to 150°C
160°C/W
100°C/W
400mW
650mW
260°C
Package Thermal Resistance (SOP-8)
Package Thermal Resistance (DIP-8)
Power Dissipation (SOP-8, at Ambient Temperature = 85°C)
Power Dissipation (DIP-8, at Ambient Temperature = 85°C)
Lead temperature (Soldering, 10sec)
ESD Voltage Protection, Human Body Model (except HV Pin)
ESD Voltage Protection, Machine Model
Gate Output Current
3KV
200V
500mA
Caution:
Stresses beyond the ratings specified in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only
rating and operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not
implied.
Recommended Operating Conditions
Item
Supply Voltage Vcc
Vcc Capacitor
Min.
11
Max.
25
Unit
V
10
47
µF
Switching Frequency
50
130
KHz
4
Leadtrend Technology Corporation
LD7575-DS-04a June 2007
