Cable Assembly Instruction I
Solder-crimp
STEP 1.
STEP 2.
STEP 3.
All parts of the connector are shown.
A crimp tool is necessary to complete the termination.
Strip the cable inner conductor, dielectric, braid, and jacket as per
"RECOMMENDED CABLE STRIPPING DIM'S" in catalog.
Slide the FERRULE onto cable Solder inner conductor to the
contact pin of MAIN BODY. And insert the MAIN BODY into
braid and dielectric.
STEP 4.
Slide the FERRULE over braid and crimp it with the crimp tool
as shown. Screw NUT onto MAIN BODY.
217
