ST72104G, ST72215G, ST72216G, ST72254G
13.1.3 Direct
ST7 ADDRESSING MODES (Cont’d)
13.1.1 Inherent
All Inherent instructions consist of a single byte.
The opcode fully specifies all the required informa-
tion for the CPU to process the operation.
In Direct instructions, the operands are referenced
by their memory address.
The direct addressing mode consists of two sub-
modes:
Inherent Instruction
Function
No operation
Direct (short)
NOP
The address is a byte, thus requires only one byte
after the opcode, but only allows 00 - FF address-
ing space.
TRAP
S/W Interrupt
Wait For Interrupt (Low Power
Mode)
WFI
Direct (long)
Halt Oscillator (Lowest Power
Mode)
HALT
The address is a word, thus allowing 64 Kbyte ad-
dressing space, but requires 2 bytes after the op-
code.
RET
Sub-routine Return
Interrupt Sub-routine Return
Set Interrupt Mask
Reset Interrupt Mask
Set Carry Flag
IRET
SIM
13.1.4 Indexed (No Offset, Short, Long)
RIM
In this mode, the operand is referenced by its
memory address, which is defined by the unsigned
addition of an index register (X or Y) with an offset.
SCF
RCF
Reset Carry Flag
Reset Stack Pointer
Load
The indirect addressing mode consists of three
sub-modes:
RSP
LD
Indexed (No Offset)
CLR
Clear
There is no offset, (no extra byte after the opcode),
and allows 00 - FF addressing space.
PUSH/POP
INC/DEC
TNZ
Push/Pop to/from the stack
Increment/Decrement
Test Negative or Zero
1 or 2 Complement
Byte Multiplication
Indexed (Short)
The offset is a byte, thus requires only one byte af-
ter the opcode and allows 00 - 1FE addressing
space.
CPL, NEG
MUL
Indexed (long)
SLL, SRL, SRA, RLC,
RRC
Shift and Rotate Operations
Swap Nibbles
The offset is a word, thus allowing 64 Kbyte ad-
dressing space and requires 2 bytes after the op-
code.
SWAP
13.1.2 Immediate
Immediate instructions have two bytes, the first
byte contains the opcode, the second byte con-
tains the operand value.
13.1.5 Indirect (Short, Long)
The required data byte to do the operation is found
by its memory address, located in memory (point-
er).
Immediate Instruction
Function
The pointer address follows the opcode. The indi-
rect addressing mode consists of two sub-modes:
LD
Load
CP
Compare
Indirect (short)
BCP
Bit Compare
The pointer address is a byte, the pointer size is a
byte, thus allowing 00 - FF addressing space, and
requires 1 byte after the opcode.
AND, OR, XOR
ADC, ADD, SUB, SBC
Logical Operations
Arithmetic Operations
Indirect (long)
The pointer address is a byte, the pointer size is a
word, thus allowing 64 Kbyte addressing space,
and requires 1 byte after the opcode.
91/140
