RTL8211C & RTL8211CL
Datasheet
7.2.8. ANNPTR (Auto-Negotiation Next Page Transmit Register,
Address 0x07)
Table 28. ANNPTR (Auto-Negotiation Next Page Transmit Register, Address 0x07)
Bit
Name
RW
Default
Description
7.15
Next Page
RW
0
Next Page Indication.
0: No more next pages to send
1: More next pages to send
Transmit Code Word Bit 15.
Transmit Code Word Bit 14.
Message Page.
7.14
7.13
RSVD
RO
0
1
Message Page
RW
0: Unformatted Page
1: Message Page
Transmit Code Word Bit 13.
Acknowledge2.
7.12
Acknowledge 2
RW
0
0: Local device has no ability to comply with the message received
1: Local device has the ability to comply with the message received
Transmit Code Word Bit 12.
Toggle bit.
7.11
Toggle
RO
0
Transmit Code Word Bit 11.
Content of Message/Unformatted Page.
Transmit Code Word Bit 10:0.
7.10:0 Message/
Unformatted Field
RW
0x001
7.2.9. ANNPRR (Auto-Negotiation Next Page Receive Register,
Address 0x08)
Table 29. ANNPRR (Auto-Negotiation Next Page Receive Register, Address 0x08)
Bit
8.15
8.14
8.13
8.12
8.11
Name
RW
RO
RO
RO
RO
RO
RO
Default Description
Next Page
Acknowledge
Message Page
Acknowledge 2
Toggle
0
Received Link Code Word Bit 15.
0
0
Received Link Code Word Bit 14.
Received Link Code Word Bit 13.
Received Link Code Word Bit 12.
Received Link Code Word Bit 11.
Received Link Code Word Bit 10:0.
0
0
8.10:0 Message/ Unformatted Field
0x00
Note: Register 8 is not valid until the Auto-Negotiation complete bit 1.5 indicates completed.
