RTL8211C & RTL8211CL
Datasheet
7.2.6. ANLPAR (Auto-Negotiation Link Partner Ability Register,
Address 0x05)
Table 26. ANLPAR (Auto-Negotiation Link Partner Ability Register, Address 0x05)
Bit
Name
RW
Default Description
5.15
Next Page
RO
0
0
0
Next Page Indication.
Received Code Word Bit 15.
Acknowledge.
5.14
5.13
ACK
RO
RO
Received Code Word Bit 14.
Remote Fault indicated by Link Partner.
Received Code Word Bit 13.
Remote Fault
5.12:5 Technology Ability Field
5.4:0 Selector Field
RO
RO
00000000 Received Code Word Bit 12:5.
00000 Received Code Word Bit 4:0.
Note: Register 5 is not valid until the Auto-Negotiation complete bit 1.5 indicates completed.
7.2.7. ANER (Auto-Negotiation Expansion Register, Address 0x06)
Table 27. ANER (Auto-Negotiation Expansion Register, Address 0x06)
Bit
Name
RW Default Description
RO 0x000 Reserved.
Parallel Detection Fault RC
6.15:5 RSVD
6.4
6.3
6.2
6.1
6.0
0
0
1
0
0
1: A fault has been detected via the Parallel Detection function
0: A fault has not been detected via the Parallel Detection function
1: Link Partner supports Next Page exchange
0: Link Partner does not support Next Page exchange
1: Local Device is able to send Next Page
Always 1.
Link Partner Next
Pageable
RO
RO
RC
RO
Local Next Pageable
Page Received
1: A New Page (new LCW) has been received
0: A New Page has not been received
Link Partner
Auto-Negotiation
capable
1: Link Partner supports Auto-Negotiation
0: Link Partner does not support Auto-Negotiation
Note: Register 6 is not valid until the Auto-Negotiation complete bit 1.5 indicates completed.
Integrated 10/100/1000 Gigabit Ethernet Transceiver
27
Track ID: JATR-1076-21 Rev. 1.3
