RDA Microelectronics, Inc.
RDA5807SP FM Tuner V1.0
9
Package Physical Dimension
Figure 9-1 illustrates the package details for the RDA5807SP. The package is lead-free and
RoHS-compliant.
MIN
NOM
4.00 BSC
4.00 BSC
2.15
MAX
D
□
E
□
D2
E2
2.00
2.00
2.25
2.25
2.15
e
□
0.50 BSC
0.40
L
b
0.30
0.18
0.80
0.00
0.50
0.30
1.00
0.05
0.25
A
0.90
A1
A3
0.02
0.20 ref
Figure 9-1 24-Pin 4x4 Quad Flat No-Lead (QFN)
