RDA Microelectronics, Inc.
RDA5807SP FM Tuner V1.0
8.2 Audio Loading Resistance Larger than 32Ω & DCXO Application:
Notes:
1. J1: Common 32Ω Resistance
Headphone;
2. U1: RDA5807SP Chip;
3. U2: 32.768KHz Crystal oscillator
4. V1: Analog and Digital Power
Supply (2.7~5.5V);
5. FM Choke (L3 and C3) for Audio
Common and LNA Input
Common;
6. Pins NC(22, 23) Should be
Leaved Floating;
7.Set MODE to select control
interface(GND—I2C,VIO—SPI);
8. Place C2 Close to AVDD pin.
Figure 8-2. RDA5807SP FM Tuner Application Diagram (DCXO Application)
8.2.1 Bill of Materials:
COMPONENT
U1
VALUE
RDA5807SP
DCXO
DESCRIPTION
Broadcast FM Radio Tuner
Crystal oscillator 32.768KHz
Common 32Ω Resistance Headphone
LC Chock for LNA Input
SUPPLIER
RDA
U2
<=50PPM
J1
L3/C3
C4,C5
C2
100nH/24pF
125µF
Murata
Murata
Murata
Murata
Audio AC Couple Capacitors
Power Supply Bypass Capacitor
FM Band Ferrite
24nF
F1/F2
1.5K@100MHz
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
Page 12 of 21
