IP1001 LF
Data Sheet
Pin no.
58
Label
Type
I
Description
MAC Interface
GMII
RGMII
MII
TX_EN
TX_CTL TX_EN
GMII and MII Transmit Enable/ RGMII Transmit
Control
I/F
MDI Description
speed
Gigabit, Indicates the valid data is
GMII 100Mbps, present on the data bus of
Mode 10Mbps TXD. Synchronous to the
rising edge of GTX_CLK
(Gigabit) or TXC_CLK
(10/100M).
Gigabit, The TX_CTL indicates a
RGMII 100Mbps, signal like TX_EN at the
Mode 10Mbps rising edge of TXC. A signal
like TX_ER is derived by the
logical operation of latched
“TX_EN” and the value at the
falling edge of TXC.
5,4,2,1
TXD[7:4] --
--
I
GMII Transmit Data (high nibble)
Please see the pin description of pin 57.
62,61,60,59 TXD[3:0] TXD[3:0] TXD[3:0] I
TX_ER -- TX_ER
GMII/RGMII/MII Transmit Data
Please see the pin description of pin 57.
6
I
GMII and MII Transmit Error
I/F
MDI Description
speed
Gigabit A “high” state present on this
pin indicates transmit data
error or carrier extension. It is
synchronous to GTX_CLK
100Mbps A “high” state present on this
, 10Mbps pin indicates transmit data
error. It is synchronous to
TX_CLK
GMII
Mode
Gigabit, Not used.
RGMII 100Mbps,
Mode 10Mbps
8/48
Dec. 18, 2007
IP1001-DS-R06
