IP1001 LF
Data Sheet
Pin description (continued)
Pin no.
LED Display
55
Label
Type
LI/O
Description
LED_MODE0
LED Mode Selection (MODE0~MODE3).
LED_MODE[1:0] can provide 4 LED display modes, Mode0~
Mode3.
LED_MODE1 is set by register16[15]. LED_MODE0 is
defined by pin or by register16[14]. The pin state of
LED_MODE0 is latched upon reset and set to register 16[14].
After power up, the designer can configure LED_MODE[1:0]
register during the operation.
Since LED_MODE1 is set to “0” upon reset, the designer can
set pin 55 to select “00” or “01” display mode if the register
16[15:14] is unchanged.
15,14,13
LED2, LED1,
LED0
IPH/O, LED output pins 0,1,2
LI/O
Mode0
00
Mode1
01
Mode2
Mode3
11
LED_Mode1,
LED_Mode0
10
LED0
LED1
LED2
10/100M Link/Act
0: link off
1: 10/100M link on
Flash: TX or RX
Bi-color mode
{LED0, LED1}=
1G Link/Act
0: link off
1: Giga link on
Flash: TX or RX
Bi-triple-color mode
{LED0, LED1}=
10= 1G Link;
01=10/100M Link;
00= link off
10= 1G Link;
01= 100M Link
00= 10M Link;
11= link off
100M Link/Act
0: link off
1: 100M link on
Flash: TX or RX
100M Link/Act
0: link off
1: 100M link on
Flash: TX or RX
11= link off
1G Link/Act
0: link off
1: Giga link on
Flash: TX or RX
Act
10M Link/Act
0: link off
1: 10M link on
Flash: TX or RX
Link/ Act
0: link off
1: 10/100M/giga link
on
0: link off or idle
1: TX or RX
Flash: TX or RX
