IP1001 LF
Data Sheet
4.5
Bit
Advertisement Register (Reg4)
HW
Reset Reset
SW
Name
Description
Type
RO
4[4:0]
Selector Filed
00001 00001
Only CSMA/CD <00001> is specified. No
other protocols are supported.
4.5
4.6
4.7
4.8
10BASE-T Half
Duplex
R/W
R/W
R/W
R/W
1
1
1
1
1
1
1
1
1 = 10Base-T full duplex is supported
0 = 10Base-T full duplex not supported
10BASE-T Full
Duplex
1 = 10Base-T half duplex is supported
0 = 10Base-T half duplex not supported
100BASE-TX Half
Duplex
1 = 100Base-TX half duplex is supported
0 = 100Base-TX half duplex not supported
100BASE-TX Full
Duplex
1 = 100Base-TX full duplex is supported
0 = 100Base-TX full duplex not supported
4.9
100BASE-T4
PAUSE
RO
Reserved 0
1 = 100Base-T4 is supported
0 = 100Base-T4 not supported
4.10
4.11
R/W
R/W
0
0
1 = flow control is supported
0 = flow control is not supported
Asymmetric Pause
1 = asymmetric flow control is supported
0 = asymmetric flow control is not supported
Ignore when read
4.12
4.13
Reserved
R/W
R/W
0
0
0
Remote Fault
1 = Advertise remote fault detection capability
0 = Not advertise remote fault detection
capability
4.14
4.15
Reserved
Next Page
Ignore when read
RO
Reserved 0
1
R/W
1 = Next pages are supported
0 = Next pages are not supported
30/48
Dec. 18, 2007
IP1001-DS-R06
Copyright © 2006, IC Plus Corp.
