IEC/EN/DIN EN 60747-5-2 Insulation Related Characteristics
Description
Symbol
PDIP Option 060
SO-8 Option 060
Units
Installation classification per DIN VDE 0110/1.89, Table 1
for rated mains voltage ≤ 150 V rms
I-IV
I-III
I-II
for rated mains voltage ≤ 300 V rms
for rated mains voltage ≤ 600 V rms
I-IV
I-III
Climatic Classification
55/85/21
55/85/21
Pollution Degree (DIN VDE 0110/1.89)
Maximum Working Insulation Voltage
Input to Output Test Voltage, Method b*
2
2
VIORM
VPR
630
560
Vpeak
Vpeak
V
IORM x 1.875 = VPR, 100% Production Test
1181
1063
with tm = 1 sec, Partial Discharge < 5 pC
Input to Output Test Voltage, Method a*
V
IORM x 1.5 = VPR, Type and Sample Test,
VPR
945
849
Vpeak
Vpeak
t
m = 60 sec, Partial Discharge < 5 pC
Highest Allowable Overvoltage*
VIOTM
6000
4000
(Transient Overvoltage, tini = 10 sec)
Safety Limiting Values
(See below for Thermal Derating Curve Figures)
Case Temperature
TS
175
230
600
150
150
600
˚C
mA
mW
Input Current
Output Power
IS,INPUT
PS,OUTPUT
Insulation Resistance at TS, VIO = 500 V
RS
≥ 109
≥ 109
Ω
*Refer to the front of the optocoupler section of the current catalog, under Product Safety Regulations section IEC/EN/DIN EN 60747-5-2, for a
detailed description.
Note: Isolation characteristics are guaranteed only within the safety maximum ratings which must be ensured by protective circuits in applica-
tion.
Thermal Derating Curve Figures
HCPL-060L/HCPL-063L
HCPL-260L/HCPL-263L
(mW)
800
700
600
500
400
300
200
100
0
800
700
600
500
400
300
200
100
0
P
(mW)
(mA)
P
S
S
I
I (mA)
S
S
0
25 50 75 100 125 150 175 200
– CASE TEMPERATURE – C
0
25 50 75 100 125 150 175 200
T – CASE TEMPERATURE – C
S
T
S
7
