Regulatory Information
The HCPL-260L/060L/263L/063L have been approved by the following organizations:
UL
Approval under UL 1577, Component Recognition Program, File E55361.
CSA
Approval under CSA Component Acceptance Notice #5, File CA 88324.
IEC/EN/DIN EN 60747-5-2
Approved under:
IEC 60747-5-2:1997 + A1:2002
EN 60747-5-2:2001 + A1:2002
DIN EN 60747-5-2 (VDE 0884
Teil 2):2003-01
(Option 060 only)
Insulation and Safety Related Specifications
8-Pin DIP
(300 Mil) SO-8
Parameter
Symbol
Value
Value
Units
Conditions
Minimum External Air
Gap (External Clearance)
L (101)
7.1
4.9
mm
Measured from input terminals to output
terminals, shortest distance through air.
Minimum External Tracking
(External Creepage)
L (102)
7.4
4.8
mm
mm
Measured from input terminals to output
terminals, shortest distance path along body.
Minimum Internal Plastic
Gap (Internal Clearance)
0.08
0.08
Through insulation distance, conductor
to conductor, usually the direct distance
between the photoemitter and
photodetector inside the optocoupler cavity.
Tracking Resistance
(Comparative Tracking Index)
CTI
200
IIIa
200
IIIa
Volts
DIN IEC 112/VDE 0303 Part 1
Isolation Group
Material Group (DIN VDE 0110, 1/89, Table 1)
6
