PRELIMINARY PRODUCT SPECIFICATION
nRF24L01 Single Chip 2.4 GHz Radio Transceiver
Package Type
Saw QFN20
(4x4 mm)
A
A1
A3
K
D/E
e
D2/E2
2.50
2.60
L
L1
b
0.80
0.85
0.95
0.00
0.02
0.05
0.35
0.40
0.45
0.18
0.25
0.30
Min
Typ.
Max
0.20
REF.
0.20 4.0 BSC12 0.5 BSC
min
0.15
max
2.70
Figure 3 nRF24L01 Package Outline.
12 BSC: Basic Spacing between Centers, ref. JEDEC standard 95, page 4.17-11/A
Nordic Semiconductor ASA - Vestre Rosten 81, N-7075 Tiller, Norway
Revision: 1.1
-
Phone +4772898900
-
Fax +4772898989
November 2005
Page 7 of 38
