void LCD_ExitSleep_ILI9320(void)
{
//*************Power On sequence ******************//
LCD_CtrlWrite_ILI9320(0x0010, 0x0000); // SAP, BT[3:0], AP, DSTB, SLP
LCD_CtrlWrite_ILI9320(0x0011, 0x0000); // DC1[2:0], DC0[2:0], VC[2:0]
LCD_CtrlWrite_ILI9320(0x0012, 0x0000); // VREG1OUT voltage
LCD_CtrlWrite_ILI9320(0x0013, 0x0000); // VDV[4:0] for VCOM amplitude
delayms(200); // Dis-charge capacitor power voltage
LCD_CtrlWrite_ILI9320(0x0010, 0x17B0); // SAP, BT[3:0], AP, DSTB, SLP, STB
LCD_CtrlWrite_ILI9320(0x0011, 0x0137); // DC1[2:0], DC0[2:0], VC[2:0]
delayms(50); // Delay 50ms
LCD_CtrlWrite_ILI9320(0x0012, 0x013C); // VREG1OUT voltage
delayms(50); // Delay 50ms
LCD_CtrlWrite_ILI9320(0x0013, 0x1600); //VDV[4:0] for VCOM amplitude
LCD_CtrlWrite_ILI9320(0x0029, 0x0000); //VCM[4:0] for VCOMH
delayms(50);
LCD_CtrlWrite_ILI9320(0x0007, 0x0173); // 262K color and display ON
}
void LCD_EnterSleep_ILI9320(void)
{
LCD_CtrlWrite_ILI9320(0x0007, 0x0000); // display OFF
//************* Power OFF sequence **************//
LCD_CtrlWrite_ILI9320(0x0010, 0x0000); // SAP, BT[3:0], APE, AP, DSTB, SLP
LCD_CtrlWrite_ILI9320(0x0011, 0x0000); // DC1[2:0], DC0[2:0], VC[2:0]
LCD_CtrlWrite_ILI9320(0x0012, 0x0000); // VREG1OUT voltage
LCD_CtrlWrite_ILI9320(0x0013, 0x0000); // VDV[4:0] for VCOM amplitude
delayms(200); // Dis-charge capacitor power voltage
LCD_CtrlWrite_ILI9320(0x0010, 0x0002); // SAP, BT[3:0], APE, AP, DSTB, SLP
}
