C L A S S
MINIATURE ENCLOSED PC BOARD RELAY - 3 TO 10 AMP
49
SPECIFICATIONS CLASS 49
DIELECTRIC STRENGTH
Contacts to coil:
COIL
Pull-in Voltage:
1,500 V rms
500 V rms
VG, VW adj. (DC) = 75% ,
VF, VG adj. (AC) = 80%,of nominal
coil voltage or less.
10% of actual pull-in or more
120% Max.
Across open contacts:
Coil to frame:
1,500 V rms
Insulation Resistance:
1000 mΩ min. @ 500 VDC
Dropout voltage:
Max. coil voltage
Duty:
TEMPERATURE
Operating:
Storage:
Continuous
-55˚C to +85˚C
-55˚C to +130˚C
Resistance:
±10%
CONTACTS
Contact Configuration:
Contact Material:
VIBRATION RESISTANCE
Functional:
SPDT
10 to 55 Hz @ 1.65mm Displacement
Silver Cad Oxide (5, 10 Amp), 3 Amp (Silver, Gold
Plated).
SHOCK RESISTANCE
Functional:
Mechanical:
Contact Resistance:
Contact Rating:
100 Milliohms Max. initial Value @ 6 Vdc, 1 Amp
10 g's
100 g's
5 and 10 Amp @ 120/240 AC, 3 Amp @ 120 VAC,
28 VDC resistive. Motor load: 1/3 Hp @120VAC,
10 Amp only.
TV 3 SPST-NO, SPST-NC, SPDT
TV 5 SPST-NO, (10 Amp only).
SPST-NO, SPST-NC, SPDT
B300
LIFE
Electrical (Rated Load):
Mechanical No Load):
100,000 Operations. .
50,000, 000 Operations.
MISCELLANEOUS
Soldering temperature:
Operating position:
Enclosure:
Pilot Duty:
270˚C (518˚F) max. for 5 seconds max..
Any.
TIMING
Dust cover.
Operate:
10 mS typical (25 mS max.)
7mS typical (10 mS max.)
Weight:
42 Grams, 1.5 oz approximately.
Release Time:
CROSS REFERENCE
COIL
PART NUMBERS
Measured @ 25˚C
Nominal
Input
Voltage
Nominal
Resistance
(Ohms)
Pull-in
Power
(mW)
PRINTED CIRCUIT BOARD MOUNTING
SPDT, 3 AMP STYLE RE1C1
CORNELL
DUBILIER
GUARDIAN
653-3K
653-6K
653-12K
3 VDC
5/6 VDC
12 VDC
6 VDC
12 VDC
24 VDC
W49RE1C1VG-3DC-SIL
W49RE1C1VG-5DC-SIL
90
235
1350
410
1640
6560
60
60
60
56
56
56
W49RE1C1VG-12DC-SIL
W49RE1C2VF-6DC-SIL
W49RE1C2VF-12DC-SIL
W49RE1C2VF-24DC-SIL
SPDT, 5 AMP STYLE RE1C1 AND RE1C2
1345-1C-5DC
1345-1C-12DC
1345-1C-24DC
603-6B
603-12B
603-24B
W49RE1C1VG-5DC-SCO
W49RE1C1VG-12DC-SCO
W49RE1C1VG-24DC-SCO
W49RE1C2VF-6DC-SCO
W49RE1C2VF-12DC-SCO
W49RE1C2VF-24DC-SCO
SPDT, 10 AMP STYLE RE1C1
5/6 VDC
12 VDC
24 VDC
6 VDC
12 VDC
24 VDC
235
1350
5400
410
1640
6560
60
60
60
56
56
56
613-6B
613-12B
613-24B
W49RE1C1VW-5DC-SCO
W49RE1C1VW-12DC-SCO
W49RE1C1VW-24DC-SCO
5/6 VDC
12 VDC
24 VDC
100
600
2400
135
135
135
SOLDER TERMINALS, BRACKET MOUNTING
SPDT, 5 AMP- STYLE R1C4
5/6 VDC
12 VDC
W49R1C4VG-5DC-SCO
W49R1C4VG-12DC-SCO
SPDT,10 AMP
60
60
235
1350
5/6 VDC
24 VDC
W49R1C4VW-5DC-SCO
W49R1C4VW-24DC-SCO
100
2400
135
135
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
PAGE 60
