C L A S S
ENCLOSED MINIATURE 2 POLE RELAY
1330 & 1335
Recognized Component mark for
SPACE SAVING DPDT, P.C. BOARD RELAY
AC OR DC OPERATED COIL.
RATED: 5 AMPS RESISTIVE, 3 AMPS INDUCTIVE
Canadian and the United States.
PENDING
C
US
UL Recognized
File No. E52197
SPECIFICATIONS CLASS 1330 & 1335
COIL
Pull-in Voltage:
Dropout:
Max. Voltage:
Coil Resistance:
Duty:
75% of Nominal Voltage or less for AC or DC Coils
DC -10% min.or more.
110%
±10% @ 25˚C
Continuous
CONTACTS
Contact Configurations:
Contact Material:
Contact Resistance:
DPDT
Silver Cadmium Oxide, .93 Dia. (2.36).
100 Milliohms Max.
MANUFACTURED UNDER
QUALITY SYSTEM
ISO 9002 & QS 9000
Contact Rating:
UL RATED - 5 Amperers @ 120 VAC resistive
NOT UL RATED - 30 VDC resistive, 3 Amperes Inductive, 1/8 Hp @ 120 VAC.
TIMING
Operate Time:
Release Time:
20mS Max. AC, 15 mS Max. DC @ Nominal Voltage, 25˚C.
20mS Max. AC, 15 mS Max. DC @ Nominal Voltage, 25˚C.
DIELECTRIC STRENGTH
Coil to Frame:
1500 V rms
500 V rms
1500 V rms
1500 Megohms Min.
Across Open Contacts:
Contact to Frame:
Insulation Resistance:
TEMPERATURE
Ambient Temperature:
-45˚C to + 70˚C @ Rated Operation.
LIFE EXPECTANCY
Mechanical
AC operated Device in excess of 50 million operations
DC operated devices, in excess of 100 million operations.
100,000 Operations Min. (at rated Resistive load).
Electrical (rated Load):
MISCELLANEOUS
Operating Position:
Insulating Material:
Enclosure:
Any.
Molded parts are diallyl phthalate for higher arc resistance.
Clear heat resistant Polycarbonate Dust Cover.
Approximately 3/4 oz.
Weight:
1.075 Max.
(27.3)
.200
Max.
.728 Max.
(18.5)
P.C. BOARD LAYOUT
CIRCUIT DIAGRAM
2
5
1
4
3
6
.728 Ref
(18.5)
.350
(8.9)
.123
(3.1)
.189
(4.8)
.905 Max.
(23)
.157
(4)
8
7
9
10
11
.354
(9)
.905 Ref
(23)
.551
(14)
.197(5)
.197(5)
.052 Typ.
(1.31)
.020 Max.
(.5) Ref.
.067 Dia.
(1.7)
8 PL
.231 Ref
(5.9)
Coil Measured at 25˚C
CROSS REFERENCE
TO
Nominal
Nominal
Resistance
(Ohms)
Nominal
Power
PART NUMBERS
Input
GUARDIAN
Voltage
AC OPERATED COILS
1.2 VA
1.2 VA
W1330P-2C-24A
W1330P-2C-120A
DC OPERATED COILS
1330P-2C-24A
1330P-2C-120A
24 VAC
120 VAC
245 Ω
5400 Ω
1.2 W
1.2 W
W1335P-2C-12D
W1335P-2C-24D
1335P-2C-12D
1335P-2C-24D
12 VDC
24 VDC
125 Ω
500 Ω
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
PAGE 63
WEBSITE: www.magnecraft.com EMAIL:info@magnecraft.com FAX ON DEMAND 1-800/891-2957 - DOCUMENT 100
