C L A S S
MINIATURE EPOXY SEALED PC BOARD POWER RELAY
76
SPECIFICATIONS CLASS 76
COIL
Pull-in Voltage:
Dropout Voltage:
Nominal Power:
Coil Resistance
TEMPERATURE
Operating:
Humidity:
DC-75% of Nominal Voltage or less
5% of Nominal Voltage or More
600 mW(1 pole) 800 mw (2 pole )Approx..
±10% Measured @ 20˚C
-30˚C to +70˚C
45 - 85% RH
VIBRATION RESISTANCE
Functional:
10 to 55 Hz Dual Amplitude 1.5mm
CONTACTS
Contact Material:
Contact Resistance:
Max.cycle rate:
Silver Cadmium Oxide
100 Milliohms Max.
30 Operations per Minute @ rated Load.
10 VDC @ 10 mA
SHOCK RESISTANCE
Functional:
10 g's Min
100 g Min.
Mechanical:
Minimum Switching Load:
LIFE
TIMING
Electrical (Rated Load):
Mechanical (No Load):
100,000 Operations min.
10,000,000 Operations min.
Operate Time:
Release Time:
Bounce Time: (Mean Value)
15 mS Max. @ Nominal Voltage.
10 mS Max. @ Nominal Voltage.
1.2 mS Approx.
MISCELLANEOUS
Operating position:
Enclosure:
Any
DIELECTRIC STRENGTH
Contacts to Coil:
Across Open Contacts:
Creepage & Clearance
Insulation Resistance:
Epoxy sealed for protection during
automatic wave soldering & cleaning
process. After cleaning process, pierce
a small hole in cover for venting.
5000 V rms, for 1 Minute
1000 V rms, for 1 Minute
8 Millimeters Min. Coil & Contacts
500VDC Exceeds 100 Megohms
Weight:
13 Grams approx.
COIL Measured @ 20˚C
CROSS REFERENCE
Nominal CONTACT
NOMINAL
INPUT
VOLTAGE
CONTACT
RATING
PART NUMBERS
POTTER &
BRUMFIELD
FIG.
Resistance
(Ohms)
OMRON
AROMAT
CONFIGU-
RATION
W76EURCPCX-14
W76EURCPCX-15
W76EURCPCX-16
W76EURCPCX-17
W76EURCPCX-18
"C"
"C"
"C"
"C"
"C"
47
68
275
1,100
4,170
G2R-14-DC5
G2R-14-DC6
JW1FEN-DC5V
JW1FEN-DC6V
G2R-14-DC12 JW1FEN-DC12V
G2R-14-DC24 JW1FEN-DC24V
G2R-14-DC48 JW1FEN-DC48V
SPDT
SPDT
SPDT
SPDT
SPDT
10 AMP
10 AMP
10 AMP
10 AMP
10 AMP
RKS-5DG-05
RKS-5DG-06
RKS-5DG-12
RKS-5DG-24
RKS-5DG-48
5 VDC
6 VDC
12 VDC
24 VDC
48 VDC
W76EURCPCX-61
W76EURCPCX-62
W76EURCPCX-63
W76EURCPCX-64
"A"
"A"
"A"
"A"
47
68
275
G2R-24-DC5
G2R-24-DC6
JW2EN-DC5V
JW2EN-DC6V
G2R-24-DC12 JW2EN-DC12V
G2R-24-DC24 JW2EN-DC24V
DPDT
DPDT
DPDT
DPDT
5 AMP
5 AMP
5 AMP
5 AMP
RKS-11DG-05
RKS-11DG-06
RKS-11DG-12
RKS-11DG-24
5 VDC
6 VDC
12 VDC
24 VDC
1,100
W76EURCPCX-146
W76EURCPCX-147
W76EURCPCX-148
W76EURCPCX-149
W76EURCPCX-150
"B"
"B"
"B"
"B"
"B"
47
68
275
1,100
4,170
G2R-1-E-DC5
G2R-1-E-DC6
G2R-1-E-DC12
G2R-1-E-DC24
G2R-1-E-DC48
SPDT
SPDT
SPDT
SPDT
SPDT
16 AMP
16 AMP
16 AMP
16 AMP
16 AMP
RKS-5DW-05
RKS-5DW-06
RKS-5DW-12
RKS-5DW-24
RKS-5DW-48
5 VDC
6 VDC
12 VDC
24 VDC
48 VDC
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
PAGE 62
