SERIES
2 COIL MOTOR REVERSING CONTACTOR 1.5 - 7.5HP, 6 POLE
A575
The Series A575 relay is rated to 7.5 HP. Two sets of 3 pole, double-make, N.O.
contacts are mechanically Interlocked to prevent simultaneous closure. Front
mounted auxiliary contacts are available for electrical lockup and lockout. All
versions have silver cadmium oxide contacts. The A575 motor reversing contactor
is widely used for control of overhead doors, elevators, hoists, machine tools, and
other similar devices that requires frequent jogging.
UL Recognized
File No. E13224
OUTLINE DIMENSIONS
Dimensions shown in Inch and (Millimeters)
NO
NO
NC
COM
NC
COM
2.56
(65.0)
4.43
(112.5)
3.40
(86.3)
MTG. HOLES
.196 DIA. (4.97)
2 PLACES
4.75
(120.6)
UP
5.25
(132)
MAXIMUM DEPTH DIMENSION OF CONTACTOR 3.00", (76.2)
RECOMMENDED
MOUNTING POSITION
WIRING DIAGRAM
1
3
6
4
Struthers-Dunn
ORDERING CODE
Typical Type No.
7
9
A575 KXX 90 -24A
Series
A575, Screw Terminals, 2 coil motor
rev. contactor, 1.5 - 7.5 HP
Contact Arrangements
KXX (3PDM-NO., per coil)
Options
1 Form SPST-NO & SPST-NC Aux. contacts
per coil, Rated 5 Amps - CODE 74
SPDT Aux. contact per coil
Rated 5 Amps. - CODE 90
Coil Voltage
AUXILIARY
CONTACTS
AC: 12, 24, 120, 240, 440, 550 (Add "A")
DC: 12, 24, 115-125, 240 (Add "D")
Mechanical Interlock omitted, Consult Factory
OPTIONS (CONSULT FACTORY)
PART NUMBER SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION
WEBSITE: www.magnecraft.com EMAIL:info@magnecraft.com FAX ON DEMAND 1-800/891-2957, DOCUMENT 100
PAGE 153
