SERIES
SCREW TERMINAL 15 AMP, 1 AND 2 POLE POWER RELAY
415
The Series 415 is a compact, 15 amp base mounted industrial relay. It is a versatile
relay that offers a variety of contact configurations and options. Excellent contact life
R
Listed (XBX Only)
file No. E13224
assures long mechanical life and contact reliability on low level loads. Screw
terminals are standard. Options include: high voltage or high inrush contacts, quick
connect terminals, permanent magnet blowout and low power DC coils.
OUTLINE DIMENSIONS
Dimensions shown in Inch and (Millimeters)
1.87
(47.4)
1.50
(38.1)
2.75
(69.85)
2.35
(59.69)
4 mtg.holes
0.181 ± .005 Dia.
MAXIMUM DEPTH DIMENSION OF CONTACTOR 1.75",
(44.45)
UP
VERTICAL MOUNTING
RECOMMENDED WITH
CONTACTS UP
WIRING DIAGRAMS
TOP VIEW
415XAX
415XBX
415XXH
415BXX
Struthers-Dunn
415HXX
ORDERING CODE
Typical Type No.
415
XBX 18 -120A
Series
415 Screw Terminals, 15 Amp
1 and 2 pole
Contact Arrangements
BXX (DPST-NO.
HXX (SPST-NO-DM
XAX (SPDT)
XBX (DPDT)
415XHX
XHX (SPDT-DB-DM
XXH (SPST-NC-DB
Options
0.25 inch quick connect terminals - CODE 18
Permanent Magnet Blowout - CODE 69
(Consult Factory for other options)
Coil Voltage
AC: 6, 12, 24, 48, 120, 240, (Add "A")
DC: 6, 12, 24, 32, 48, 115-125 (Add "D")
Special coils: Low Power (mW), series coils.
High Inrush contacts: 10 Amps continuous, 150 Amp Inrush.
High Voltage Contacts: Up to 4KV
