Si3210/Si3211/Si3212
Register 18. Interrupt Status 1
Bit
D7
D6
D5
D4
D3
D2
D1
D0
Name
Type
PMIP
R/W
PMAP
R/W
RGIP
R/W
RGAP
R/W
O2IP
R/W
O2AP
R/W
O1IP
R/W
O1AP
R/W
Reset settings = 0000_0000
Bit
Name
Function
7
PMIP
Pulse Metering Inactive Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
6
5
4
3
2
1
0
PMAP
RGIP
RGAP
O2IP
Pulse Metering Active Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Ringing Inactive Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Ringing Active Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Oscillator 2 Inactive Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
O2AP
O1IP
Oscillator 2 Active Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Oscillator 1 Inactive Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
O1AP
Oscillator 1 Active Timer Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Preliminary Rev. 1.11
65
