Si3210/Si3211/Si3212
Register 22. Interrupt Enable 2
Bit
D7
D6
D5
D4
D3
D2
D1
D0
Name
Type
Q6AE
R/W
Q5AE
R/W
Q4AE
R/W
Q3AE
R/W
Q2AE
R/W
Q1AE
R/W
LCIE
R/W
RTIE
R/W
Reset settings = 0000_0000
Bit
Name
Function
7
Q6AE
Power Alarm Q6 Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
6
5
4
3
2
1
0
Q5AE
Q4AE
Q3AE
Q2AE
Q1AE
LCIE
Power Alarm Q5 Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
Power Alarm Q4 Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
Power Alarm Q3 Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
Power Alarm Q2 Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
Power Alarm Q1 Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
Loop Closure Transition Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
RTIE
Ring Trip Interrupt Enable.
0 = Interrupt masked.
1 = Interrupt enabled.
Preliminary Rev. 1.11
69
