Si3210/Si3211/Si3212
Register 19. Interrupt Status 2
Bit
D7
D6
D5
D4
D3
D2
D1
D0
Name
Type
Q6AP
R/W
Q5AP
R/W
Q4AP
R/W
Q3AP
R/W
Q2AP
R/W
Q1AP
R/W
LCIP
R/W
RTIP
R/W
Reset settings = 0000_0000
Bit
Name
Function
7
Q6AP
Power Alarm Q6 Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
6
5
4
3
2
1
0
Q5AP
Q4AP
Q3AP
Q2AP
Q1AP
LCIP
Power Alarm Q5 Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Power Alarm Q4 Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Power Alarm Q3 Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Power Alarm Q2 Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Power Alarm Q1 Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
Loop Closure Transition Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
RTIP
Ring Trip Interrupt Pending.
Writing 1 to this bit clears a pending interrupt.
0 = No interrupt pending.
1 = Interrupt pending.
66
Preliminary Rev. 1.11
