Si3210/Si3211/Si3212
Register 3. PCM Transmit Start Count—High Byte
Bit
D7
D6
D5
D4
D3
D2
D1
D0
Name
Type
TXS[9:8]
R/W
Reset settings = 0000_0000
Bit
7:2
1:0
Name
Function
Reserved
TXS[9:8]
Read returns zero.
PCM Transmit Start Count.
PCM transmit start count equals the number of PCLKs following FSYNC before data
transmission begins. See Figure 27 on page 46.
Register 4. PCM Receive Start Count—Low Byte
Bit
D7
D6
D5
D4
D3
D2
D1
D0
Name
Type
RXS[7:0]
R/W
Reset settings = 0000_0000
Bit
Name
Function
7:0
RXS[7:0]
PCM Receive Start Count.
PCM receive start count equals the number of PCLKs following FSYNC before data
reception begins. See Figure 27 on page 46.
Register 5. PCM Receive Start Count—High Byte
Bit
D7
D6
D5
D4
D3
D2
D1
RXS[9:8]
R/W
D0
Name
Type
Reset settings = 0000_0000
Bit
7:2
1:0
Name
Function
Reserved
RXS[9:8]
Read returns zero.
PCM Receive Start Count.
PCM receive start count equals the number of PCLKs following FSYNC before data
reception begins. See Figure 27 on page 46.
Preliminary Rev. 1.11
57
