Si3210/Si3211/Si3212
Register 6. Digital Input/Output Control
Si3210
Bit
D7
D6
D5
D4
D3
D2
D1
D0
Name
Type
Reset settings = 0000_0000
Si3211/Si3212
D4
Bit
D7
D6
D5
D3
D2
D1
D0
Name
Type
DOUT
DIO2
R/W
DIO1
R/W
PD2
R/W
PD1
R/W
R/W
Reset settings = 0000_0000
Bit
7:5
4
Name
Reserved
DOUT
Function
Read returns zero.
DOUT Pin Output Data (Si3211/Si3212 only).
0 = DOUT pin driven low.
1 = DOUT pin driven high.
Si3210 = Reserved.
3
2
1
DIO2
DIO1
PD2
DIO2 Pin Input/Output Direction.
0 = DIO2 pin is an input.
1 = DIO2 pin is an output and driven to value of the PD2 bit.
Si3210 = Reserved.
DIO1 Pin Input/Output Direction.
0 = DIO1 pin is an input.
1 = DIO1 pin is an output and driven to value of the PD1 bit.
Si3210 = Reserved.
DIO2 Pin Data.
When DIO2 = 1:
0 = DIO2 pin driven low.
1 = DIO2 pin driven high.
Si3210 = Reserved.
When DIO2 = 0, PD2 value equals the logic input of DIO2 pin.
0
PD1
DIO1 Pin Data.
When DIO1 = 1:
0 = DIO1 pin driven low.
1 = DIO1 pin driven high.
Si3210 = Reserved.
When DIO1 = 0, PD1 value equals the logic input of DIO1 pin.
58
Preliminary Rev. 1.11
