PCT1789W DATA SHEET
PCT303DW CONTROL REGISTERS
!!
International Control 1
(Register 16, R/W)
ONS[1:0]
ACT
IIRE
DCT[1:0]
RZ
RT
7
6
5
4
3
2
1
0
Reset settings: 08h
Bit Definitions:
Bits
Name
Description
On-hook speed.
ONS[1:0]
7:6
ONS[1:0]
Description
00
11
The PCT303DW will execute a slow controlled on-hook.
The PCT303DW will execute a fast on-hook.
5
4
ACT
AC termination select.
1 = Selects the complex impedance.
0 = Selects the real impedance.
IIRE
IIR filter enable.
1 = IIR filter enabled for transmit and receive filters. (See Figures 25–28 on page 61.)
0 = FIR filter enabled for transmit and receive filters. (See Figures 21–24 on page 60.)
3:2
DCT[1:0]
DC termination select.
DCT[1:0] Mode
Description
Low voltage mode. See “Appendix: NET4 Country Support” on page 65.
(Transmit level = –2dBm).
00
01
0
1
Low voltage mode. Provides different I/V characteristics than mode 0.
(Transmit level = –5dBm).
10
11
2
3
Standard voltage mode. (Transmit level = –1dBm).
Current limiting mode. (Transmit level = –1dBm).
1
0
RZ
RT
Ringer impedance select.
When set, ringer impedance is decreased to satisfy some countries’ ringer require-
ments.
Ringer threshold select.
Used to satisfy country requirements on ring detection. Signals below the lower level
will not generate a ring detection; signals above the upper level are guaranteed to
generate a ring detection.
1 = 15 ±5 Vrms
0 = 21.5 ±4.5 Vrms
