PCT2303N DATA SHEET
ELECTRICAL CHARACTERISTICS
!!
ELECTRICAL CHARACTERISTICS
Recommended Operating Conditions
Table 6 Recommended Operating Conditions
Parameter a
Min b
Max b
Symbol
TA
Test Condition
K-grade
Typ
25
Unit
°C
°C
V
Ambient temperature
0
70
Ambient temperature
TA
B-grade
0
25
90
PCT303A supply voltage, analog
PCT303A supply voltage, digital c
VA
4.50
3.0
5.0
5.50
5.50
VD
3.3/5.0
V
a. The PCT2303N chipset specifications are guaranteed when the typical application circuit (including component
tolerance) and any PCT303A and PCT303L are used.
b. All minimum and maximum specifications are guaranteed and apply across the recommended operating conditions.
Typical values apply at nominal supply voltages and an operating temperature of 25°C unless otherwise stated.
c. The digital supply, VD, can operate from either 3.3V or 5.0V. The PCT303A supports interface to 3.3V logic when
operating from 3.3V. The 3.3V operation applies to both the serial port and the digital signals RESET, ID0, and ID1.
Absolute Maximum Ratings
Permanent device damage may occur if the absolute maximum ratings are exceeded. Functional operation should
be restricted to the conditions as specified in the operational sections of this data sheet. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
Table 7 Absolute Maximum Ratings
Parameter
Symbol
Value
Unit
DC supply voltage
VD, VA
–0.5 to +6.0
V
Input current, PCT303A digital input pins
Digital input voltage
IIN
VIND
TA
±10
mA
V
–0.3 to (VD+0.3)
–10 to +100
–40 to +150
Operating temperature range
Storage temperature range
°C
°C
TSTG
