CPD-E200E
• Convergence Rough Adjustment
(2) Digital Convergence
1. Enter the white crosshatch signal (white lines on black).
2. Adjust roughly the horizontal and vertical convergence at
four-pole magnet.
Convergence (Low) Mode
1. Adjust the H. STAT and V. STAT with "HSTAT" and
"VSTAT".
3. Adjust roughly HMC and VMC at six-pole magnet.
A. Horizontal Convergence
YBH-T-LO
• Convergence Adjustment
(1) Static convergence
9
5
10
18
2
CBH-T-L-LO
MBH-T-L-LO
APH-L-LO
CBH-T-R-LO
MBH-T-R-LO
APH-R-LO
1. Receive the crosshatch of R and B.
2. Adjust H. STAT and V. STAT by 4 pole magnet.
3. Recieve the white crosshatch signal.
4. Adjust HMC and VMC by 6 pole magnet.
5. Recieve the crosshatch of R and B.
Note: Adjust H. STAT and V. STAT in the beggining by 4 pole
magnet not adjuust them by register immediately.
6. Insert to TLH correction board and correct H. TILT.
7. Correct XCV by XCV core.
17
1
HSTAT
19
11
20
12
MBH-B-L-LO
CBH-B-L-LO
MBH-B-R-LO
CBH-B-R-LO
6
YBH-B-LO
Adjust each misconvergence point in sequence.
B. Vertical Convergence
8. Correct V. TILT by TLV-VR.
9. Adjust Y cross by YCH-VR.
10. Correct to get the most suitable convergence pattern.
When necessary, adjust above mentioned from step 1 to step
9 reiterate.
11. Paint lock TLH corection board, neck assy 4 and 6 pole
magnet.
V STAT-T-LO
7
13
21
3
14
22
4
CCV-T-L-LO
MCV-T-L-LO
XBV-L-LO
CCV-T-R-LO
MCV-T-R-LO
XBV-R-LO
Purity Mg
VSTAT
4-pole Mg
XCV
6-pole Mg
23
15
24
16
MCV-B-L-LO
CCV-B-L-LO
MCV-B-R-LO
CCV-B-R-LO
YCH
8
V STAT-B-LO
TLV
H-Trap
Adjust each misconvergence point in sequence.
TLH
2. Repeat the procedure of A and B so that the convergence of
the entire screen is within the specification.
XCV
YCH
B
R
Convergence (Hight) Mode
1. Adjust the H. STAT and V. STAT with "HSTAT-HI" and
"VSTAT-HI".
R
B
A. Horizontal Convergence
TLV
TLH
YBH-T-HI
R
B
9
5
10
18
2
CBH-T-L-HI
MBH-T-L-HI
APH-L-HI
CBH-T-R-HI
MBH-T-R-HI
APH-R-HI
17
1
B
R
R
B
B
R
HSTAT-HI
19
11
20
12
MBH-B-L-HI
CBH-B-L-HI
MBH-B-R-HI
CBH-B-R-HI
<<Neck Assy's Zero Position>>
4 Pole
6 Pole
6
YBH-B-HI
Purity
Adjust each misconvergence point in sequence.
4-2
