10.6.52 QOSC38 - CREDIT_C5_G0
Serial Interface Address:h54F
Bits [5:0]
Bits [7:6]:
•
•
W5 - Credit register. (Default 5'h8)
Reserved
10.6.53 QOSC39- CREDIT_C6_G0
Serial Interface Address:h550
Bits [5:0]
Bits [7:6]:
•
•
W6 - Credit register. (Default 5'h8)
Reserved
10.6.54 QOSC3A- CREDIT_C7_G0
Serial Interface Address:h551
Bits [5:0]
Bits [7:6]:
•
•
W7 - Credit register. (Default 5'h10)
Reserved
QOSC33 through QOSC3Arepresents the set of WFQ parameters (see section 7.5) for Gigabit port 0. The
granularity of the numbers (bits [5:0]) is 1, and their sum must be 64. QOSC33 corresponds to W0, and QOSC3A
corresponds to W7.
Classes WFQ Credit Port G1
10.6.55 QOSC3B - CREDIT_C0_G1
Serial Interface Address:h552
Bits [5:0]:
Bits [7:6]:
•
W0 - Credit register for WFQ. (Default 6'h04)
Priority type. Define one of the four QoS mode of operation for port 1 (Default 2'00)
- 00: Option 1
- 01: Option 2
- 10: Option 3
- 11: Option 4
See table below:
Queue
P7
P6
P5
P4
P3
P2
P1
P0
Option 1 Bit [7:6] = 2'B00 DELAY BOUND
BE
BE
Option 2 Bit [7:6] = 2'B01 SP
Option 3 Bit [7:6] = 2'B10 SP
DELAY BOUND
WFQ
Option 4 Bit [7:6] = 2'B11
Credit for WFQ - Bit [5:0]
WFQ
W7
W6
W5
W4
W3
W2
W1
W0
52
