MVTX2801
Data Sheet
10.6.33 QOSC0A - BYTE_C6_G1
2
I C Address h05F, Serial Interface Address:h521
Bits [7:0]:
•
Byte count threshold for C6 queue WRED (Default 8'h50)
(64 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.34 QOSC0B - BYTE_C7_G1
2
I C Address h060, Serial Interface Address:h522
Bits [7:0]:
•
Byte count threshold for C7 queue WRED (Default 8'h50)
(64 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
QOSC06 through QOSC0B represent the values F-A in Table 3. They are per-queue byte thresholds for random
early drop. QOSC0B represents A, and QOSC06 represents F.
Classes Byte Gigabit Port 2
10.6.35 QOSC0C - BYTE_C2_G2
2
I C Address h061, Serial Interface Address:h523
Bits [7:0]:
•
Byte count threshold for C2 queue WRED (Default 8'h28)
(1024 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.36 QOSC0D - BYTE_C3_G2
2
I C Address h062, Serial Interface Address:h524
Bits [7:0]:
•
Byte count threshold for C3 queue WRED (Default 8'h28)
(512 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.37 QOSC0E - BYTE_C4_G2
2
I C Address h063, Serial Interface Address:h525
Bits [7:0]:
•
Byte count threshold for C4 queue WRED (Default 8'h28)
(256 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
48
