MVTX2801
Data Sheet
10.6.38 QOSC0F - BYTE_C5_G2
2
I C Address h064, Serial Interface Address:h526
Bits [7:0]:
•
Byte count threshold for C5 queue WRED (Default 8'h28)
(128 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.39 QOSC10 - BYTE_C6_G2
2
I C Address h065, Serial Interface Address:h527
Bits [7:0]:
•
Byte count threshold for C6 queue WRED (Default 8'h50)
(64 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.40 QOSC11 - BYTE_C7_G2
2
I C Address h066, Serial Interface Address:h528
Bits [7:0]:
•
Byte count threshold for C7 queue WRED (Default 8'h50)
(64 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
QOSC0C through QOSC11 represent the values F-A in Table 3 for Gigabit port 2. They are per-queue byte
thresholds for random early drop. QOSC11 represents A, and QOSC0C represents F.
Classes Byte Gigabit Port 3
10.6.41 QOSC12 - BYTE_C2_G3
2
I C Address h067, Serial Interface Address:h529
Bits [7:0]:
•
Byte count threshold for C2 queue WRED (Default 8'h28)
(1024 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.42 QOSC13 - BYTE_C3_G3
2
I C Address h068, Serial Interface Address:h52A
Bits [7:0]:
•
Byte count threshold for C3 queue WRED (Default 8'h28)
(512 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.43
QOSC14 - BYTE_C4_G3
2
I C Address h069, Serial Interface Address:h52B
Bits [7:0]:
•
Byte count threshold for C4 queue WRED (Default 8'h28)
(256 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
49
