MVTX2801
Data Sheet
10.6.27 QOSC04 - BYTE_C6_G0
2
I C Address h059, Serial Interface Address:h51B
Bits [7:0]:
•
Byte count threshold for C6 queue WRED (Default 8'h50)
(64byte/unit when Delay Bound is used)
(1024byte/unit when WFQ is used)
10.6.28 QOSC05 - BYTE_C7_G0
2
I C Address h05A, Serial Interface Address:h51C
Bits [7:0]:
•
Byte count threshold for C6 queue WRED (Default 8'h50)
(64byte/unit when Delay Bound is used)
(1024byte/unit when WFQ is used)
QOSC00 through QOSC05 represent the values F-A in Table 3 for Gigabit port 0. They are per-queue byte
thresholds for weighted random early drop (WRED). QOSC05 represents A, and QOSC00 represents F.
Classes Byte Gigabit Port 1
10.6.29 QOSC06 - BYTE_C2_G1
2
I C Address h05B, Serial Interface Address:h51D
Bits [7:0]:
•
Byte count threshold for C2 queue WRED (Default 8'h28)
(1024byte/unit when Delay Bound is used)
(1024byte/unit when WFQ is used)
10.6.30 QOSC07 - BYTE_C3_G1
2
I C Address h05C, Serial Interface Address:h51E
Bits [7:0]
•
Byte count threshold for C3 queue WRED (Default 8'h28)
(512 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
10.6.31 QOSC08 - BYTE_C4_G1
2
I C Address h05D, Serial Interface Address:h51F
Bits [7:0]:
•
Byte count threshold for C4 queue WRED (Default 8'h28)
(256 byte/unit when Delay Bound is used)
(1024byte/unit when WFQ is used)
10.6.32 QOSC09 - BYTE_C5_G1
2
I C Address h05E, Serial Interface Address:h520
Bits [7:0]:
•
Byte count threshold for C5 queue WRED (Default 8'h28)
(128 byte/unit when Delay Bound is used)
(1024 byte/unit when WFQ is used)
47
Zarlink Semiconductor Inc.
