MVTX2801
Data Sheet
(G_RCLK & G_REFCLK = 125MHz)
G8
G[3:0]_CRS Input Hold Times
1
1
1
1
G12
G13
G14
G[3:0]_TXD[7:0] Output Delay Times
G[3:0]_TX_EN Output Delay Times
G[3:0]_TX_ER Output Delay Times
5
5
5
C = 20pf
L
C = 20pf
L
C = 20pf
L
Table 15 - AC Characteristics - Gigabit Media Independent Interface (continued)
11.5.6 PCS Interface
G[3:0]_TXCLK
G30-max
G30-min
G[3:0]_TXD[9:0]
Figure 15 - AC Characteristics - PCS Interface
G[3:0]_RXCLK1
G[3:0]_RXCLK
G[3:0]_RXD[9:0]
G[3:0]_RX_CRS
Figure 16 - AC Characteristics - PCS Interface
(G_RCLK & G_REFCLK =
125MHz)
Symbol
Parameter
Min (ns)
Max (ns)
Note:
G21
G[3:0]_RXD[9:0] Input Setup Times ref to
G_RXCLK
2
G22
G23
G[3:0]_RXD[9:0] Input Hold Times ref to
G_RXCLK
1
2
G[3:0]_RXD[9:0] Input Setup Times ref to
G_RXCLK1
Table 16 - AC Characteristics - PCS Interface
100
