WM8352
Production Data
29.5 LDO REGULATOR EXTERNAL COMPONENTS
The recommended connections to the LDO Regulators are illustrated in Figure 92.
Figure 92 LDO Regulators External Components
When selecting suitable capacitors, is it imperative that the effective capacitance is within the
required limits at the applicable input/output voltage of the converter. Ceramic X7R or X5R types are
recommended.
Wolfson recommends the following external components for use with LDO Regulators 1, 2, 3 and 4.
Note that larger capacitors will improve load transient response and power supply rejection. A
maximum of 10μF is possible at the output; a maximum of 1μF is possible at the input.
COMPONENT
VALUE
1μF
0.1μF
PART NUMBER
SIZE
0402
0603
COUT
CIN
Murata GRM155R60J105KE19D
Phycomp 06032R104K7B2
Table 160 Recommended External Components - LDO1, LDO2, LDO3 and LDO4
PD, February 2011, Rev 4.4
332
