W90N745CD/W90N745CDG
USB Endpoint B Interrupt Clear Register (EPB_IC)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
USB endpoint
register
B
interrupt clear
EPB_IC
0xFFF06070
W
0x0000_0000
31
23
30
22
29
21
28
20
27
26
18
25
17
24
16
Reserved
19
Reserved
11
15
7
14
6
13
12
10
2
9
1
8
0
Reserved
3
5
4
EPB_BUS_ERR_IC
EPB_CF_IC
EPB_DMA_IC
EPB_ALT_IC
EPB_TK_IC
EPB_STL_IC
Reserved
BITS
DESCRIPTIONS
[31:6]
Reserved
[5]
[4]
[3]
[2]
[1]
[0]
EPB_CF_IC
Endpoint B clear feature interrupt clear
EPB_BUS_ERR_IC
EPB_DMA_IC
EPB_ALT_IC
EPB_TK_IC
Endpoint B system bus error interrupt clear
Endpoint B DMA transfer complete interrupt clear
Endpoint B alternate setting interrupt clear
Endpoint B token input interrupt clear
Endpoint B stall interrupt clear
EPB_STL_IC
USB Endpoint B Interrupt Status Register (EPB_IS)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
USB endpoint
register
B
interrupt status
EPB_IS
0xFFF06074
R
0x0000_0000
