W83195WG-382/W83195CG-382
STEPLESS FOR ATI K8 CLOCK GENERATOR
Read Back only. Timeout Flag.
0
1 : Watchdog has ever started and count to zero.
0 : a.) Watchdog is restarted and counting.
b.) Power on default state
5
WD_TIMEOUT
R
4
3
2
1
0
SAF_FREQ<4>
SAF_FREQ<3>
SAF_FREQ<2>
SAF_FREQ<1>
SAF_FREQ<0>
0
0
0
1
0
These bits will be reloaded in Reg-0 to select
frequency table. As the watchdog is timeout and
EN_SAFE_FREQ=1.
R/W
7.7 Register 6: ( Default : FFh )
AFFECTED PIN/
BIT
PWD
FUNCTION DESCRIPTION
TYPE
FUNCTION NAME(S)
SRC7 output control
1: Enable
7
SRCEN<7>
1
R/W
0: Disable
SRC6 output control
1: Enable
0: Disable
6
5
4
3
SRCEN<6>
SRCEN<5>
SRCEN<4>
SRCEN<3>
1
1
1
1
R/W
R/W
R/W
R/W
SRC5 output control
1: Enable
0: Disable
SRC4 output control
1: Enable
0: Disable
SRC3 output control
1: Enable
0: Disable
ATIG1 output control
1: Enable
0: Disable
2
1
0
ATIGEN<1>
ATIGEN<0>
SRCEN<0>
1
1
1
R/W
R/W
R/W
ATI clock can’t be controlled by CLKREQ# pins
ATIG0 output control
1: Enable
0: Disable
ATI clock can’t be controlled by CLKREQ# pins
SRC0 output control
1: Enable
0: Disable
Publication Release Date: Feb 2006
Revision 0.6
- 9 -
