I5216 SERIES
Advanced Information
PRELIMINARY
I2C SLAVE ADDRESS
The I5216 has a 7 bit slave address of <100 00xy> where x and y are equal to the state, respectively,
of the external address pins A1 and A0. Because all data bytes are required to be 8 bits, the LSB of the
address byte is the Read/Write selection bit that tells the slave whether to transmit or receive data.
Therefore, there are eight possible slave addresses for the I5216
A1 A0 Slave Address
R/W\
Bit
HEX Value
0
0
1
1
0
1
0
1
<100 00 00>
<100 00 01>
<100 00 10>
<100 00 11>
0
0
0
0
80
82
84
86
0
0
1
1
0
1
0
1
<100 00 00>
<100 00 01>
<100 00 10>
<100 00 11>
1
1
1
1
81
83
85
87
To use more than four I5216 devices in an application requires some external switching of the I2C link.
Publication Release Date: November 30, 2001
-18
Revision A1
