I5216 SERIES
Advanced Information
PRELIMINARY
CFG1
Bit no.
D0 (LSB)
D1
Signal
AGPD
FLPD
FLD0
FLD1
FLS0
S2M0
S2M1
S1M0
S1M1
S1S0
S1S1
VOL0
VOL1
VOL2
VLS0
VLS1
Description
Power down the Microphone AGC
Power down the Filter
D2
Set the duration and sample rate of the ChipCorder
Set the duration and sample rate of the ChipCorder
Select the filter input signal
D3
D4
D5
Select Sum Amplifier 2 input
Select Sum Amplifier 2 input
Select Sum Amplifier 1 input
Select Sum Amplifier 1 input
Select Sum Amplifier 1 multiplexer
Select Sum Amplifier 1 multiplexer
Volume Control Setting
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15 (MSB)
Volume Control Setting
Volume Control Setting
Select Volume Control input
Select Volume Control input
Publication Release Date: November 30, 2001
Revision A1
