TPS20xxC, TPS20xxC-2
SLVSAU6G –JUNE 2011–REVISED JULY 2013
www.ti.com
REVISION HISTORY
Changes from Original (June 2011) to Revision A
Page
•
•
Changed the TPS2051C, TPS2065C, and TPS2069C Devices Status From: Preview To: Active ...................................... 1
Corrected pinout numbers for the 5-PIN PACKAGE ............................................................................................................ 7
Changes from Revision A (July 2011) to Revision B
Page
•
•
Added the DGK Package Information throughout the data sheet ........................................................................................ 1
Changed title of Figure 17 From: NEW FIG To: TPS2065C 50 Ω Short Circuit ................................................................... 9
Changes from Revision B (September 2011) to Revision C
Page
•
•
Changed TPS2000C (MSOP-8) status From: Preview To: Active in Table 1 ...................................................................... 1
Changed From: PXF1 To: PXFI and From: PSG1 To: PXGI in the DEVICE INFORMATION table MOSP-8 (DGK)
column .................................................................................................................................................................................. 2
•
•
Changed the θJACustom 2 A Rated DGK value from N/A to 110.3 .................................................................................... 2
Added Figure 45 - DGK Package PCB Layout Example .................................................................................................... 17
Changes from Revision C (October 2011) to Revision D
Page
•
•
•
Added Feature UL Listed and CB-File No. E169910 (See Table 1) .................................................................................... 1
Added table Note 2, UL listed and CB complete. ................................................................................................................. 1
Added VIH and VIL information to the ROC Table ................................................................................................................. 3
Changes from Revision D (February 2012) to Revision E
Page
•
Changed the POWER DISSIPATION AND JUNCTION TEMPERATURE section. Replaced paragraph " While it is
recommended..." ................................................................................................................................................................. 16
18
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
