TPS1H100-Q1
www.ti.com.cn
ZHCSDD8D –OCTOBER 2014–REVISED DECEMBER 2019
6.7 Switching Characteristics
VVS = 13.5 V, Rload = 10 Ω, over operating free-air temperature range (unless otherwise noted)(1)
PARAMETER
Turn-on delay time
Turn-off delay time
Slew rate on
TEST CONDITIONS
IN rising edge to VOUT = 10%, DIAG_EN high
IN falling edge to VOUT = 90%, DIAG_EN high
VOUT = 10% to 90%, DIAG_EN high
MIN
20
TYP
MAX
50
UNIT
µs
td,ON
td,OFF
dV/dtON
20
50
µs
0.1
0.5
V/µs
V/µs
V/µs
dV/dtOFF Slew rate off
Slew rate on and off matching
VOUT = 90% to 10%, DIAG_EN high
0.1
0.5
–0.15
0.15
(1) Value specified by design, not subject to production test.
In
90%
90%
Vout
10%
10%
Td,ON dV/dtON
Td,OFF dV/dtOFF
Figure 5. Switching Characteristics Diagram
