TMS570LS3137
SPNS162.–SEPTEMBER 2011
www.ti.com
UNIT
3.5 Power Consumption Over Recommended Operating Conditions
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
fHCLK = 160MHz for
PGE Package
350 for PGE
Package
fHCLK = 180MHz for
ZWT Package
VCC digital supply current (operating mode)
mA
375 for ZWT
Package
fVCLK
=
90MHz,
Flash in pipelined
mode, VCCmax
ICC
LBIST clock rate =
90MHz
VCC Digital supply current (LBIST mode)
mA
mA
400
Peak
PBIST ROM clock
frequency = 90MHz
TBD
VCC Digital supply current
(PBIST mode)
RMS
405
10
ICCPLL
ICCIO
VCCPLL digital supply current (operating mode)
VCCIO Digital supply current (operating mode.
VCCPLL = VCCPLLmax
No DC load, VCCmax
mA
mA
15
Single ADC
operational,
VCCADmax
15
ICCAD
VCCAD supply current (operating mode)
mA
mA
Both ADCs
operational,
VCCADmax
30
5
Single ADC
operational,
ADREFHImax
ICCREFHI
ADREFHI supply current (operating mode)
Both ADCs
operational,
ADREFHImax
10
34
read operation
VCCPmax
program, VCCPmax
37
55
read from 1 bank
and program
another bank,
VCCPmax
ICCP
VCCP pump supply current
mA
erase, VCCPmax
27
44
Device Operating Conditions
