TMS320TCI6487
TMS320TCI6488
Communications Infrastructure Digital Signal Processor
SPRS358F–APRIL 2007–REVISED AUGUST 2008
www.ti.com
Table 8-78. Antenna Interface System Registers (continued)
HEX ADDRESS
02BE 5010
ACRONYM
PD_LINK2_CPRI_SI_LUT1_CFG
REGISTER NAME
PD CPRI Stream Index LUT1 Register
02BE 5014 - 02BE 57FC
02BE 5800
-
Reserved
PD_LINK3_84CNT_LUT0_CFG
PD_LINK3_84CNT_LUT1_CFG
PD_LINK3_84CNT_LUT2_CFG
PD_LINK3_CPRI_SI_LUT0_CFG
PD_LINK3_CPRI_SI_LUT1_CFG
-
PD 84 Count Look-Up Table bits [31:0]
PD 84 Count Look-Up Table bits [63:32]
PD 84 Count Look-Up Table bits [83:64]
PD CPRI Stream Index LUT0 Register
PD CPRI Stream Index LUT1 Register
Reserved
02BE 5804
02BE 5808
02BE 580C
02BE 5810
02BE 5814 - 02BE 5FFC
02BE 6000
PD_LINK4_84CNT_LUT0_CFG
PD_LINK4_84CNT_LUT1_CFG
PD_LINK4_84CNT_LUT2_CFG
PD_LINK4_CPRI_SI_LUT0_CFG
PD_LINK4_CPRI_SI_LUT1_CFG
-
PD 84 Count Look-Up Table bits [31:0]
PD 84 Count Look-Up Table bits [63:32]
PD 84 Count Look-Up Table bits [83:64]
PD CPRI Stream Index LUT0 Register
PD CPRI Stream Index LUT1 Register
Reserved
02BE 6004
02BE 6008
02BE 600C
02BE 6010
02BE 6014 - 02BE 67FC
02BE 6800
PD_LINK5_84CNT_LUT0_CFG
PD_LINK5_84CNT_LUT1_CFG
PD_LINK5_84CNT_LUT2_CFG
PD_LINK5_CPRI_SI_LUT0_CFG
PD_LINK5_CPRI_SI_LUT1_CFG
-
PD 84 Count Look-Up Table bits [31:0]
PD 84 Count Look-Up Table bits [63:32]
PD 84 Count Look-Up Table bits [83:64]
PD CPRI Stream Index LUT0 Register
PD CPRI Stream Index LUT1 Register
Reserved
02BE 6804
02BE 6808
02BE 680C
02BE 6810
02BE 6814 - 02BE 6FFC
02BE 7000
PD_0_CFG
Protocol Decoder Configuration Register 0
Protocol Decoder Configuration Register 1
02BE 7004
PD_1_CFG
02BE 7008
PD_ADR_MUX_SEL_CFG
PD_TYPE_CIR_LUT_CFG
Protocol Decoder OBSAI Adr Mux Select Register
02BE 700C
Protocol Decoder Type CirSw Capture Enable LUT
Register
02BE 7010
PD_TYPE_PKT_LUT_CFG
Protocol Decoder Type PktSw Capture Enable LUT
Register
02BE 7014
02BE 7018 - 02BE 77FC
02BE 7800
PD_TYPE_ERR_LUT_CFG
-
Protocol Decoder Type Error Register
Reserved
PD_ADR_LUT
Protocol Decoder Address Look Up Table Register
Reserved
02BE 7804 - 02BE 7FFC
02BE 8000
-
PE_LINK0_84_EN_LUT0_CFG
PE_LINK0_84_EN_LUT1_CFG
PE_LINK0_84_EN_LUT2_CFG
PE_LINK0_TERM_CNT01_CFG
PE_LINK0_TERM_CNT23_CFG
-
PE 84 Count Message Enable bits [31:0]
PE 84 Count Message Enable bits [63:32]
PE 84 Count Message Enable bits [83:64]
PE Transmission Rule Terminal Count 0 and 1
PE Transmission Rule Terminal Count 2 and 3
Reserved
02BE 8004
02BE 8008
02BE 800C
02BE 8010
02BE 8014 - 02BE 81FC
02BE 8200 - 02BE 834C
02BE 8350 - 02BE 83FC
02BE 8400 - 02BE 8450
02BE 8454 - 02BE 84FC
02BE 8500 - 02BE 8550
02BE 8554 - 02BE 87FC
02BE 8800
PE_LINK0_84CNT_LUT
-
PE 84 Count LUT RAM
Reserved
PE_LINK0_ID_LUT0
-
PE Identity LUT Part 0 RAM
Reserved
PE_LINK0_ID_LUT1
-
PE Identity LUT Part 1 RAM
Reserved
PE_LINK1_84_EN_LUT0_CFG
PE_LINK1_84_EN_LUT1_CFG
PE_LINK1_84_EN_LUT2_CFG
PE_LINK1_TERM_CNT01_CFG
PE_LINK1_TERM_CNT23_CFG
PE 84 Count Message Enable bits [31:0]
PE 84 Count Message Enable bits [63:32]
PE 84 Count Message Enable bits [83:64]
PE Transmission Rule Terminal Count 0 and 1
PE Transmission Rule Terminal Count 2 and 3
02BE 8804
02BE 8808
02BE 880C
02BE 8810
190
Peripheral Information and Electrical Specifications
