Table 8-60. Timer 3 Registers (continued)
HEX ADDRESS
0294 0030
ACRONYM
REGISTER NAME
-
Reserved
Reserved
0294 0034 - 0294 FFFF
-
Table 8-61. Timer 4 Registers
HEX ADDRESS
0295 0000
ACRONYM
REGISTER NAME
PID
Peripheral ID Register
0295 0004
EMUMGT_CLKSPD
Timer 4 Emulation Management/Clock Speed Register
Reserved
0295 0008
-
-
0295 000C
Reserved
0295 0010
TIMLO
TIMHI
PRDLO
PRDHI
TCR
TGCR
WDTCR
-
Timer 4 Counter Register Low
Timer 4 Counter Register High
Timer 4 Period Register Low
Timer 4 Period Register High
Timer 4 Control Register
Timer 4 Global Control Register
Timer 4 Watchdog Timer Control Register
Reserved
0295 0014
0295 0018
0295 001C
0295 0020
0295 0024
0295 0028
0295 002C
0295 0030
-
Reserved
0295 0034 - 0295 FFFF
-
Reserved
Table 8-62. Timer 5 Registers
HEX ADDRESS
0296 0000
ACRONYM
REGISTER NAME
Peripheral ID Register
PID
0296 0004
EMUMGT_CLKSPD
Timer 5 Emulation Management/Clock Speed Register
Reserved
0296 0008
-
-
0296 000C
Reserved
0296 0010
TIMLO
TIMHI
PRDLO
PRDHI
TCR
TGCR
WDTCR
-
Timer 5 Counter Register Low
Timer 5 Counter Register High
Timer 5 Period Register Low
Timer 5 Period Register High
Timer 5 Control Register
Timer 5 Global Control Register
Timer 5 Watchdog Timer Control Register
Reserved
0296 0014
0296 0018
0296 001C
0296 0020
0296 0024
0296 0028
0296 002C
0296 0030
-
Reserved
0296 0034 - 0296 FFFF
-
Reserved
Table 8-63. Timer Device-Specific Registers
HEX ADDRESS
0290 0000
ACRONYM
TINPSEL
REGISTER NAME
Timer Input Selection
0290 0004
TOUTPSEL
WDRSTSEL
Timer Output Selection
Watchdog Timer Reset Select
0290 0008
158
Peripheral Information and Electrical Specifications
