TMS320TCI6487
TMS320TCI6488
Communications Infrastructure Digital Signal Processor
www.ti.com
SPRS358F–APRIL 2007–REVISED AUGUST 2008
Table 8-10. EDMA3 Transfer Controller 5 Registers (continued)
HEX ADDRESS RANGE
ACRONYM
SACNTRLD
SASRCBREF
SADSTBREF
-
REGISTER NAME
02A4 8258
02A4 825C
Source Active Count Reload Register
Source Active Source Address B-Reference Register
Source Active Destination Address B-Reference Register
Reserved
02A4 8260
02A4 8264 - 02A4 827C
02A4 8280
DFCNTRLD
DFSRCBREF
DFDSTBREF
-
Destination FIFO Set Count Reload
Destination FIFO Set Destination Address B Reference Register
Destination FIFO Set Destination Address B Reference Register
Reserved
02A4 8284
02A4 8288
02A4 828C - 02A4 82FC
02A4 8300
DFOPT0
DFSRC0
DFCNT0
DFDST0
DFBIDX0
DFMPPRXY0
-
Destination FIFO Options Register 0
Destination FIFO Source Address Register 0
Destination FIFO Count Register 0
Destination FIFO Destination Address Register 0
Destination FIFO BIDX Register 0
02A4 8304
02A4 8308
02A4 830C
02A4 8310
02A4 8314
Destination FIFO Memory Protection Proxy Register 0
Reserved
02A4 8318 - 02A4 833C
02A4 8340
DFOPT1
DFSRC1
DFCNT1
DFDST1
DFBIDX1
DFMPPRXY1
-
Destination FIFO Options Register 1
Destination FIFO Source Address Register 1
Destination FIFO Count Register 1
Destination FIFO Destination Address Register 1
Destination FIFO BIDX Register 1
02A4 8344
02A4 8348
02A4 834C
02A4 8350
02A4 8354
Destination FIFO Memory Protection Proxy Register 1
Reserved
02A4 8358 - 02A4 837C
02A4 8380
DFOPT2
DFSRC2
DFCNT2
DFDST2
DFBIDX2
DFMPPRXY2
-
Destination FIFO Options Register 2
Destination FIFO Source Address Register 2
Destination FIFO Count Register 2
Destination FIFO Destination Address Register 2
Destination FIFO BIDX Register 2
02A4 8384
02A4 8388
02A4 838C
02A4 8390
02A4 8394
Destination FIFO Memory Protection Proxy Register 2
Reserved
02A4 8398 - 02A4 83BC
02A4 83C0
DFOPT3
DFSRC3
DFCNT3
DFDST3
DFBIDX3
DFMPPRXY3
-
Destination FIFO Options Register 3
Destination FIFO Source Address Register 3
Destination FIFO Count Register 3
Destination FIFO Destination Address Register 3
Destination FIFO BIDX Register 3
02A4 83C4
02A4 83C8
02A4 83CC
02A4 83D0
02A4 83D4
Destination FIFO Memory Protection Proxy Register 3
Reserved
02A4 83D8 - 02A4 FFFC
Submit Documentation Feedback
Peripheral Information and Electrical Specifications
101
