The .L and .S units can now support up to 64-bit operands. This allows for new versions of many of the arithmetic,
logical, and data packing instructions to allow for more parallel operations per cycle. Additional instructions were
added yielding performance enhancements of the floating point addition and subtraction instructions, including the
ability to perform one double precision addition or subtraction per cycle. Conversion to/from integer and
single-precision values can now be done on both .L and .S units on the C66x. Also, by taking advantage of the larger
operands, instructions were also added to double the number of these conversions that can be done. The .L unit also
has additional instructions for logical AND and OR instructions, as well as, 90 degree or 270 degree rotation of
complex numbers (up to two per cycle). Instructions have also been added that allow for the computing the
conjugate of a complex number.
The MFENCE instruction is a new instruction introduced on the C66x DSP. This instruction will create a DSP stall
until the completion of all the DSP-triggered memory transactions, including:
•
•
•
•
•
•
Cache line fills
Writes from L1D to L2 or from the CorePac to MSMC and/or other system endpoints
Victim write backs
Block or global coherence operations
Cache mode changes
Outstanding XMC prefetch requests
This is useful as a simple mechanism for programs to wait for these requests to reach their endpoint. It also provides
ordering guarantees for writes arriving at a single endpoint via multiple paths, multiprocessor algorithms that
depend on ordering, and manual coherence operations.
For more details on the C66x DSP and its enhancements over the C64x+ and C674x architectures, see the following
documents:
•
C66x CPU and Instruction Set Reference Guide in ‘‘Related Documentation from Texas Instruments’’ on
page 69.
•
•
C66x DSP Cache User Guide in ‘‘Related Documentation from Texas Instruments’’ on page 69.
C66x CorePac User Guide in ‘‘Related Documentation from Texas Instruments’’ on page 69.
